160ltr Blow Molding Machine for Open-top Barrels
160ltr Blow Molding Machine for Open-top Barrels
160ltr Blow Molding Machine for Open-top Barrels

160ltr Blow Molding Machine for Open-top Barrels


Place of Origin:China
Brand Name:Jwell
Certification:ISO CE UL TUV
Competitive advantage:High quality, high capacity,high stability, worldwide after-sales service, more than 40 years developing experience


Add to Basket
Applications

● Suitable for producing different kinds of safety barrel, traffic divided blocks.
● Optional bottom sealing, product eject, core-pulling movement elements.
● Adopt high output extrusion system, accumulating die head.
● Optional Hydraulic Servo control system.

Description

JWZ-BM series blow-molding machine are suitable for large-scale production of milk-bottle, drink-bottle, water-bottle, hot–filling bottle, medical containers, container used for cosmetic, spices, pesticides, lubricants and computer suppliers, it is also applicable for making small plastic toys.

In order to improve the efficiency, short the time that used for bottle forming, we equip with post-cooling device, so the products have good quality. According to the requirement of the customer, we can equip with other downstream equipments, so that the line can convey the finished products and trim waste-margin automatically.

Specifications
ModelUnitBM160
Max product volumeL160
Dry cyclePc/h300
Die head structureAccumulating type
Main screw diametermm100
Max plasticizing capacity (PE)kg/h240
Driving motorKw90
Accumulating volumeL18
Oil pump motor power(Servo)Kw22
Clamping forceKN800
Space between platenmm500-1400
Platen size W*Hmm1120*1200
Max. mold sizemm900*1450
Heating power of die headKw30
Machine dimension L*W*Hm7*3.5*4
Machine weightT20
Total powerKw172

Note:Information listed above are for reference only, the production line can be designed by customer’s requirements.
