JWELL Starch Filled Bio-plastic Compounding Line
JWELL Starch Filled Bio-plastic Compounding Line
JWELL Starch Filled Bio-plastic Compounding Line
JWELL Starch Filled Bio-plastic Compounding Line

JWELL Starch Filled Bio-plastic Compounding Line


Place of Origin:China
Brand Name:Jwell
Certification:ISO CE UL TUV
Competitive advantage:High quality, high capacity,high stability, worldwide after-sales service, more than 40 years developing experience


Add to Basket
Applications

Disposable lunch boxes, knives and forks, straws, cups, shopping bags, courier bags, mulching film and other degradable products.

Description

Starch filled bio-plastic compounding line is composed of four parts. They are dosing system、compounding system、underwater cutting system、downstream auxiliary equipment.

Dosing system contains vacuum loader for pellet、refill silo for pellet、single screw loss in weight feeder、vacuum loader for powder、refill silo for powder、twin screw loss in weight feeder、liquid loss in weight feeder.

According to the independent and accurate dosing system, raw material of bio-plastic, starch and plasticizer are added to the twin screw extruder, which has a high degree of automation and strong elasticity of formula adjustment.

Compounding system has control cabinet、gearbox、safety clutch、main extruder and main motor. Efficient heating and precise control to ensure stable,reliable and long term production.

Underwater cutting system includes water circulation system、cutter、water tank、dewatering unit. The closed system is enviromental with no emission of smoke and dust.

Competitive Advantage
ModelL/D ratioSpeedMotor powerTorque levelCapacity for referenceTypical formula
CJWH-5240-56300rpm45KW9N.m/cm3150kg/hrBio-plastic
+55%Starch
+15%Glycerine
CJWH-6540-56300rpm75KW9N.m/cm3240kg/hr
CJWH-7540-56300rpm132KW9N.m/cm3440kg/hr
CJWH-9540-56300rpm250KW9N.m/cm3820kg/hr
CJWS-5240-56300rpm55KW11N.m/cm3190kg/hr
CJWS-6540-56266rpm90KW11N.m/cm3310kg/hr
CJWS-7540-56300rpm160KW11N.m/cm3550kg/hr
CJWS-9540-56300rpm315KW11N.m/cm31060kg/hr
CJWS-75 Plus44-56330rpm200KW13.5N.m/cm3700kg/hr


Process steps

Progress

Shipment

packing
