Jwell Two Shaft Recycling Shredder
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability,worldwide after-sales service, more than 30 years developing experience |
Applications
This series of shredder is specially suitable for shredding large-size plastic materials.
Description
This series of two-shaft shredder features low noise, low energy consumption and high output. it reflects the superiority of low speed and large torque cutting design. This series of shredders is particularly suitable for the crushing of large-sized plastic materials. After being shredded,the bull density of the material can be increased, thereby reducing transportation costs, in addition,the material can be further processed after shredding such as material separation, washing and pelletizing etc.
Specifications
| MODEL | Rotor Dia(mm) | Drive Power(kw) | Rotor Blade(pcs) | Blade Thickness(mm) | Crushing Chamber Size Max(mm) |
| DYTSS-32100 | Ф430 | 22*2 | 26 | 40 | 1000×800 |
| DYTSS-40130 | Ф514 | 37*2 | 26 | 50 | 1300×950 |
| DYTSS-50180 | Ф615 | 55*2 | 36 | 50 | 1800×1200 |
Process steps
Shipment
FAQ
Q: What equipment does JWELL mainly produce?
A: All kinds of sheet& plate extrusion lines, pipe extrusion lines, profile extrusion lines, compounding lines, recycling machines, blow-molding machines, chemical fiber equipment and other core parts.
Q: Do you provide installation and commissioning services for overseas projects?
A: Yes, we can provide
Q: Does the machines comply with international certifications CE and ISO?
A: yes.
