APET PETG CPET Sheet Extrusion Line
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability, worldwide after-sales service, more than 30 years developing experience |
Applications
PETG is called low temperature PET, it’s a new environment-friendly packing material with features such as high luster, good transparency, excellent barrier property, self-adhesion, which is used for glue bonding and high-frequency processing.
CPET is a kind of modified PET with good resistance to high temperature, it is usually used for package in microwave oven.
PET Stereoscopic Optical Grating Sheet: It can be used as top grade package for cosmetics, medicine, tobacco&alcohol and common goods such as stationery, advertisements, posters and all kinds of cards.
Description
It is one of the most advanced production lines in China, with mature technology and good stability. Compared with other similar equipment, the efficiency of the whole machine is increased by more than 30%. The production line is also suitable for PS, PP, PE.
Specifications
| Model | Multi layer | Single layer | Highly-efficient |
| Extruder spcification | JW120/65-1000 | JW120-1000 | JW120-1500 |
| Product thickness | 0.2-1.5mm | 0.15-1.5mm | 0.15-1.5mm |
| Main motor power | 110kw/45kw | 110kw | 160kw |
| Max capacity | 500kg/h | 450kg/h | 800kg/h |
Process steps
Shipment
