HDPE Marine Pipe Extrusion Line
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability, worldwide after-sales service, more than 30 years developing experience |
Applications
Used in rivers, lakes, moorings, ponds, etc.
Description
This production line adopts the most advanced technology of Europe,It is a new research achievement of energy- saving production line,which is suitable for high speed extrusion of HDPE and other polyolefin pipe.compared with common production line,the energy-saving effect reach on 35%,and the product efficiency increase more than 1 times, thus it is not only saving the cost of site and manpower, but also improving efficiency.
Specifications
| Type | Pipe spec (mm) | Extruder | Max.output (kg/h) | Total power (kw) |
| JWGXPE-110 | Φ20-Φ110 | JWSG-60/38 | 420 | 166 |
| JWGXPE-250 | Φ75-Φ250 | JWSG-75/38 | 650 | 245 |
| JWGXPE-450 | Φ160-Φ450 | JWSG-90/38 | 950 | 450 |
Process steps
Shipment
