JWGK Series Fully Automatic PVC Pipe Belling Machine
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability, worldwide after-sales service, more than 30 years developing experience |
Applications
Widely used in packaging, electronics, printing, nameplate, signage and other industries.
Description
The belling system uses advanced European technology for PVC solid wall pipes and double wall corrugated pipes in the form of rectangular flaring and U- and R-shaped flaring. The control is automatically controlled by Japanese Mitsubishi PLC program, which is stable and reliable, and the flaring mould is hydraulically driven. Main production range is Φ 32 - Φ 800.
Specifications
| Type | JWGK110 | JWGK250 | JWGK450 | JWGK630 | JWGK800 |
| Dia(mm) | ф32-110 | ф63-250 | ф160-450 | Ф315-630 | Ф400-800 |
| Hydraulic pressure rated(mpa) | 3Mpa | 3Mpa | 5Mpa | 5Mpa | 5Mpa |
| Compressed air(mpa) | 0.4Mpa | 0.4Mpa | 0.4Mpa | 0.4Mpa | 0.4Mpa |
| Power(Kw) | 10kw | 20kw | 25kw | 40kw | 60kw |
