Jwell Heavy Single Shaft Recycling Shredder
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability,worldwide after-sales service, more than 30 years developing experience |
Applications
DYSSZ series shredders can meet the recycling and high production capacity requirements of various industries that are dificult to shred. can beused to shred all kinds of plastic large solid block, extrusion lumps, pallets, hollow barrels, thick plates and films, etc.
Description
DYSSZ series shredder is a multifunctional machine. Using standardized module design, combined with rich crushing experience, the torque, speed, action program, and tool configuration have corresponding parameter configurations for different material processing. This series shredders are designed to meet the requirements of various industries for the recycling and high productivity of difficult-to-shred waste.
Specifications
| MODEL | Rotor blade swing diameter(mm) | Drive power(KW) | Rotor blade quantity(pcs) | Fixed blade quantity(pcs) | Crush chamber size max(mm) |
| DYSSZ-1000 | Ф400 | 2*22 | 57 | 5 | 850*1300*350 |
| DYSSZ-1400 | Ф630 | 2*37 | 102 | 7 | 1200*1300*550 |
| DYSSZ-1600 | Ф750 | 2*55 | 117 | 8 | 1500*1400*600 |
| DYSSZ-2000 | Ф750 | 2*75 | 147 | 10 | 1500*1800*600 |
| DYSSZ-2500 | Ф750 | 2*90 | 177 | 12 | 1500*2200*600 |
| DYSSZ-3000 | Ф750 | 2*132 | 218 | 14 | 1800*2800*600 |
Process steps
Shipment
FAQ
Q: What equipment does JWELL mainly produce?
A: All kinds of sheet& plate extrusion lines, pipe extrusion lines, profile extrusion lines, compounding lines, recycling machines, blow-molding machines, chemical fiber equipment and other core parts.
Q: Do you provide installation and commissioning services for overseas projects?
A: Yes, we can provide
Q: Does the machines comply with international certifications CE and ISO?
A: yes.
