Single Stage Pelletizing Machine
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity,high stability,Worldwide after-sales service, more than 40 years developing experience |
Applications
With special screw design and different configurations, it is suitable for the regeneration and granulation of various plastics such as PP, PE, PS, ABS, and PC,etc.
Description
The gearbox adopts a high-torque design to achieve low noise and stable operation.The screw and barrel have undergone special surface treatment, which has the characteristics of wear resistance, good mixing effect and high output. The design of vacuum exhaust or natural exhaust port can remove moisture and exhaust gas during the production process, so that the output is more stable, the particles are more dense, and the excellent quality of the product is guaranteed.
Specifications
| MODEL | SCREW DIAMETER (MM) | L/D | SCREW SPEED (RPM) | POWER OF MAIN MOTOR(KW) | OUT PUT(KG/H) |
| JWL45 | 45 | 25-35 | 20-100 | 11-15 | 30-50 |
| JWL65 | 65 | 25-35 | 20-100 | 30-37 | 60-120 |
| JWL90 | 90 | 25-35 | 20-90 | 45-55 | 180-200 |
| JWL120 | 120 | 25-35 | 20-75 | 75-110 | 250-350 |
Process steps
Shipment
FAQ
Q: What equipment does JWELL mainly produce?
A: All kinds of sheet& plate extrusion lines, pipe extrusion lines, profile extrusion lines, compounding lines, recycling machines, blow-molding machines, chemical fiber equipment and other core parts.
Q: Do you provide installation and commissioning services for overseas projects?
A: Yes, we can provide
Q: Does the machines comply with international certifications CE and ISO?
A: yes.
