Jwell Large diameter Pipe Recycling System
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability,worldwide after-sales service, more than 30 years developing experience |
Applications
DYSSG shredder can be used to shred the PE, PP, PVC pipe with a diameter of 1600mm, and pipes with a length of 3-6m can be directly shredded without cutting
Description
The pipe is pushed to the center of the shaft by hydraulica to crush. The crushed materials enter the crusher through the conveyor belt for secondary crushing to achieve the required crushing particle size. Materials are fully and effectively crushed in the crushing chamber.
Video
Specifications
| MODEL | ROTOR BLADE SWING DIAMETER(MM) | DRIVE POWER(KW) | MAX. SHREDDER PIPE(DIAMETER MM) | OUT PUT(KG/H) |
| DYSSG- 630 | Ф848 | 2*30 | 630 | 800-1000 |
| DYSSG- 800 | Ф1028 | 2*37 | 800 | 1000-1200 |
| DYSSG- 1000 | Ф1258 | 2*45 | 1000 | 1200-1500 |
| DYSSG- 1200 | Ф1478 | 2*55 | 1200 | 1500-2000 |
| DYSSG- 1600 | Ф1968 | 2*110 | 1600 | 1800-2500 |
Process steps
Shipment
FAQ
Q: What equipment does JWELL mainly produce?
A: All kinds of sheet& plate extrusion lines, pipe extrusion lines, profile extrusion lines, compounding lines, recycling machines, blow-molding machines, chemical fiber equipment and other core parts.
Q: Do you provide installation and commissioning services for overseas projects?
A: Yes, we can provide
Q: Does the machines comply with international certifications CE and ISO?
A: yes.
