JWELL PVC windows High Speed Profile Extrusion Line
| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability, worldwide after-sales service, more than 30 years developing experience |
Applications
Suitable for the production of PVC material door and window series profiles, sheets, micro-foam profiles, micro-foam decorative sheets, etc.
Description
Properties:
The unit consists of twin-screw extruder, vacuum calibration table, Haul off unit, cutter, film covering machine, stacker, etc.
It adopts imported AC frequency conversion or DC speed regulation to drive, and the temperature control instrument adopts imported brand.The calibration unit’s pump and haul off adopt high-quality products,it is easy to maintain,after replacing the screw barrel and mold, the foam profile can be directly extruded, and the effect is better than that of a single screw.
Advantages:
uniform plasticization, low shear rate, high output, and long service life and so on.
Specifications
| Model | YF240 | YF240 | YF240A |
| Max.width(mm) | 240 | 240 | 240 |
| Extruder model | SJP75/28 | SJP93/28/31 | SJP110/28 |
| Max.capacity(kg/h) | 150-250 | 250-400 | 400-500 |
| Extruder power(kw) | 37 | 55 | 75 |
| Cooling water(m3/h) | 7 | 8 | 10 |
| Compressed air(m3/min) | 0.6 | 0.6 | 0.8 |
| Model | SJZ55/110 | SJZ65/132 | SJZ80/156 |
| Screw speed(rpm) | 34.7 | 34.7 | 34.7 |
| Motor Power(kw) | 22 | 37 | 55 |
| Output(kg/h) | 100/150 | 180/250 | 300/400 |
| Center high(mm) | 1050 | 1050 | 1050 |
| Weight(kg) | 3500 | 4000 | 5500 |
